Product Feature:

.Black panel,both dignified and graceful.
.Poweramp adopt audio grade with 805 output high power tubes as single-ended
class A power amplification.
.Extraposition 805 current adjustment(BIAS ADJ.)and hum balance adjustment
(HUM BALANCE).
.You can use a variety of brands and models tubes,listen to the different rhyme.
.Totallyhandmade,The whole machine adopts some welding booths.
.Interstage use the German high quality N - cap coupling capacitance.
.Using two high quality EI to promote output transformer and output transformer.
.Using the specifical development for the native circular area power transformer.
.With high pressure power supply and the filament preheating function,extend the
life of the tube.
.Select the Japan ALPS high-grade motor potentiometer.
.Infrared remote control function.

Specification:

Power output： 48W＋48W
Frequency response： 10Hz～50kHz（-1.5dB）
THD： 1%（1kHz）
S/N Ratio： 87dB A Weighted
Input Sensitivity： 200mV（Integrated）

Input Impedance： 100kΩ
Output Impedance： 4Ω ， 8Ω ， 16Ω
Dimension (WxDxH)： 430mmX420mmX270mm
Tube Complement： 6SL7 x1、6SN7 x2、805 x2、300B x2 Net Weight： 40kg
Power Consumption： 400W
Working Condition: Temperature: 0℃～40℃ Moisture: 20%～80%
Storage Condition: Temperature: -20℃～70℃ Moisture: 20%～90%
