Product features
●Hand-made construction with the finest point-to-point wiring.
●Specially designed EI transformer for power supply.
●Two EI output transformers with wide bandwidth are applied.
●Two 12AX7s and 12BH7s are used in the preamp stage.
●Four KT88 tubes are used for AB1 push-pull amplification.
●Provide the triode and superlinear selection function. Triode, voice soft, pure and
smooth, suitable for appreciation vocals, string and other types of music; Superlinear
works, Yang loud, bold and unrestrained, imposing manner is good, suitable for enjoy big
scenes, such as large dynamic types of music.
●Triode and Ultralinear selection.
●SoftStart and time-delay circuit. (30 seconds)
●ALPS volume control and Realcap capacitors are applied.
●Remote control for all functions.
●User bias control is accessible on top of the amplifiers panel with true ampere meter.
●Convenient installation drawing plug-in valve cap


Specification:
－Power output：15W+15W（RMS Triode operation）
32W+32W（RMS Ultralinear operation）
－Frequency response：10Hz～50kHz（-1.5dB）
－THD：1%（1kHz）
－S/N Ratio：87dB
－Input Sensitivity：220mV
－Input Impedance：100kΩ
－Output Impedance：4Ω ，8Ω
－Dimension (WxDxH)： （373 x 345 x 191.5）mm3
－Tube Complement：12AX7 x2、12BH7 x2、KT88x4
－Net weight: 19.6kg
－Power Consumption：240W
－Working Condition: Temperature: 0℃～40℃ Moisture: 20%～80%
－Storage Condition: Temperature: -20℃～70℃ Moisture: 20%～90%
